Baking Type Zinc Flake Coating Self Dry Silver Top Coat 2 Adhesion Increase Surface Hardness
Baking Type Zinc Flake Coating Self Dry Silver Top Coat 2 Adhesion Increase Surface HardnessDescription
Specifications
| 1 | Color |
| 2 | coating thickness(μ) |
| 3 | non-volatile % |
| 4 | Adhesion≤ |
| 5 | Flexibility(mm)≤ |
| 6 | hardness |
| 7 | impact resistance(KG.CM) |
| 8 | wet and heat(h) |
| Place of Origin: | Changzhou in china |
| Brand Name: | JUNHE |
| Certification: | ISO9001 SGS |
| Model Number: | JH-9028 |
| Minimum Order Quantity: | 100Kiloamperes |
| Price: | US $6.3 - 6.8 / Kiloampere |
| Packaging Details: | 15kg/ Metal Barrel |
| Delivery Time: | Ten days after receipt of advance payment |
| Supply Ability: | 2 Ton/Tons per Day |
| Main Raw Material: | Water-based Inorganic Silica |
| Flexibility(mm): | â¤3 |
| Adhesion: | ⤠2 |
| Impact Resistance(KG.CM): | 50 |
| Highlight: | Anti Corrosion Coating,Zinc Nickel Plating |
| No. | Item |
| Large Image :Baking Type Zinc Flake Coating Self Dry Silver Top Coat 2 Adhesion Increase Surface Hardness | Large Image :Baking Type Zinc Flake Coating Self Dry Silver Top Coat 2 Adhesion Increase Surface Hardness |
| Zinc Flake Coating | Chrome Free Water Based Zinc Flake Coating Salt Fog Time 480 Hours PH ( 20â ) 5.0-8.0 |
| Zinc Flake Coating Machine | No Effusion Zinc Flake Coating Machine Aluminium Coating Machine With Single Basket |
Baking Type Zinc Flake Coating Self Dry Silver Top Coat 2 Adhesion Increase Surface HardnessDescription
Baking Type Zinc Flake Coating Self Dry Silver Top Coat 2 Adhesion Increase Surface Hardness
Anti Corrosion Coating
Zinc Nickel Plating
Baking type top coating top coating after zinc flake coating specific weight 0.9-1.2g/mlProduct Description:In view of the defects of poor corrosion resistance of galvanized parts and the lack of acid and alkali resistance of coatings, we have developed JH-9028 baking type top coatings. It can improve the anti-corrosion performance of the whole coating, increase the salt spray time to more than 1000 hours, increase the hardness, acid and alkali resistance of the surface, and diversify the surface color.The main ingredient is water-base inorganic silica , mixed with corrosion protection assistant.The product cost is low.Technical Data:No.ItemData1ColorSilver2coating thickness(μ)First coating≥153non-volatile %304Adhesion≤25Flexibility(mm)≤36hardness0.77impact resistance(KG.CM)508wet and heat(h)240Instructions and attention:Dip coating,Spray coating etc.It should be stirred fully befor usage; distilled water or deionized water can be used to adjust viscosity ;Operating viscosity:30-60s.When the environment humidity higher than 85%,can add certain industrial alcohol to adjust viscosityCuring condition: 80â/10min+140â/30minCleaning appliance: running water can be usedAvoid acid substances, or polymerization and deterioration will happen.This product can be used alone,the coated surface request oil free,dust free and dry,the better make pre-treatment of degreasing,derusting,and phosphating.Processing method:A 1 base-coat+ 1 Top coatB 2 base-coat+ 1 Top coat (heavy corrosion protection)Process Parameter:Dip Coating Temperature RTOperateing Viscosity 45-60 SCentrifuge 210270 RPM/min 10s X 4-8 times( Centrifuge device can not be mix used with spin dyrer )Spray Coating Temperature RTOperateing Viscosity 3040 SCuring: 80â 10min + 140â 20—30minCorrosion protection of b process flowCorrosion resistance: ≥1500h (NSS)Sea water resistance: 25â≥1500h
Baking type top coating top coating after zinc flake coating specific weight 0.9-1.2g/ml
Product Description:
In view of the defects of poor corrosion resistance of galvanized parts and the lack of acid and alkali resistance of coatings, we have developed JH-9028 baking type top coatings. It can improve the anti-corrosion performance of the whole coating, increase the salt spray time to more than 1000 hours, increase the hardness, acid and alkali resistance of the surface, and diversify the surface color.The main ingredient is water-base inorganic silica , mixed with corrosion protection assistant.The product cost is low.Technical Data:No.ItemData1ColorSilver2coating thickness(μ)First coating≥153non-volatile %304Adhesion≤25Flexibility(mm)≤36hardness0.77impact resistance(KG.CM)508wet and heat(h)240Instructions and attention:Dip coating,Spray coating etc.It should be stirred fully befor usage; distilled water or deionized water can be used to adjust viscosity ;Operating viscosity:30-60s.When the environment humidity higher than 85%,can add certain industrial alcohol to adjust viscosityCuring condition: 80â/10min+140â/30minCleaning appliance: running water can be usedAvoid acid substances, or polymerization and deterioration will happen.This product can be used alone,the coated surface request oil free,dust free and dry,the better make pre-treatment of degreasing,derusting,and phosphating.Processing method:A 1 base-coat+ 1 Top coatB 2 base-coat+ 1 Top coat (heavy corrosion protection)Process Parameter:Dip Coating Temperature RTOperateing Viscosity 45-60 SCentrifuge 210270 RPM/min 10s X 4-8 times( Centrifuge device can not be mix used with spin dyrer )Spray Coating Temperature RTOperateing Viscosity 3040 SCuring: 80â 10min + 140â 20—30minCorrosion protection of b process flowCorrosion resistance: ≥1500h (NSS)Sea water resistance: 25â≥1500h
In view of the defects of poor corrosion resistance of galvanized parts and the lack of acid and alkali resistance of coatings, we have developed JH-9028 baking type top coatings. It can improve the anti-corrosion performance of the whole coating, increase the salt spray time to more than 1000 hours, increase the hardness, acid and alkali resistance of the surface, and diversify the surface color.
The main ingredient is water-base inorganic silica , mixed with corrosion protection assistant.The product cost is low.
Technical Data:
Instructions and attention:
Dip coating,Spray coating etc.
It should be stirred fully befor usage; distilled water or deionized water can be used to adjust viscosity ;Operating viscosity:30-60s.
When the environment humidity higher than 85%,can add certain industrial alcohol to adjust viscosity
Curing condition: 80â/10min+140â/30min
Cleaning appliance: running water can be used
Avoid acid substances, or polymerization and deterioration will happen.
This product can be used alone,the coated surface request oil free,dust free and dry,the better make pre-treatment of degreasing,derusting,and phosphating.
Processing method:
A 1 base-coat+ 1 Top coat
B 2 base-coat+ 1 Top coat (heavy corrosion protection)
Process Parameter:
Dip Coating Temperature RT
Operateing Viscosity 45-60 S
Centrifuge 210~270 RPM/min 10s X 4-8 times
( Centrifuge device can not be mix used with spin dyrer )
Spray Coating Temperature RT
Operateing Viscosity 30~40 S
Curing: 80â 10min + 140â 20—30min
Corrosion protection of b process flow
Corrosion resistance: ≥1500h (NSS)
Sea water resistance: 25â≥1500h
Tag:Zinc Nickel Plating,Mechanical Zinc Plating,Anti Corrosion Coating
